Sku: BF-8655
dTrite-Pro Electronic Titrator
Description
Electronic titration is a new product in the field of titration, which is easier, more comfortable, faster and more accurate than a traditional buret. For laboratories that require standardised operation and traceable data, the dTrite-Pro electronic titrator drives the whole titration process electronically. Compared with ordinary digital titrators, this electronic titration is more accurate, stable, efficient and free from human influence, which greatly improves detection ability, makes laboratory operation more standardised and enables data traceability.
dTrite-Pro is applied to all experiments of acid-base neutralisation titration, redox titration, precipitation titration and complexation titration. It is widely used in the food industry, the pharmaceutical and chemical industry, food and drug safety testing, petrochemicals, environmental testing, metals and plating, surfactants, and third-party testing laboratories. The titration data can be traced.
Specification
| Property | Value |
|---|---|
| Product | dTrite-Pro Electronic Titrator |
| Titration Sizes | 10 mL, 25 mL, 50 mL |
| Resolution | Up to two decimal places |
| Quality Standard | ISO 8655 |
| Operating Temperature Range | 10–30 °C |
| Bluetooth Function | Yes |
| WiFi Function | Yes |
| Control Type | Remote support, including stirrers and titration programmes |
| Battery Capacity | 3500 mAh |
| Memory | 1000 experimental records |
| Screen | 4.3-inch TFT color display, 800×480 resolution |
| Suction & Discharge Speed Range | 0.1–2 mL/s, 0.1–5 mL/s, 0.1–10 mL/s |
Volume range by model:
| Model | Volume Range | Max. per Aspiration | Min. Volume |
|---|---|---|---|
| 10 mL | 0.010 mL – 99.999 mL | 10 mL | 10 μL |
| 25 mL | 0.020 mL – 99.999 mL | 25 mL | 20 μL |
| 50 mL | 0.020 mL – 99.999 mL | 50 mL | 20 μL |
Working accuracy:
| Model | Nominal Volume (mL) | Systematic Error R (±μL / ±%) | Coefficient of Variation CV (±μL / ±%) |
|---|---|---|---|
| 10 mL | 10 / 5 / 1 | 20 / 20 / 20 · 0.2 / 0.4 / 2.0 | 7 / 7 / 7 · 0.07 / 0.14 / 0.7 |
| 25 mL | 25 / 12.5 / 2.5 | 50 / 50 / 50 · 0.2 / 0.4 / 2.0 | 17.5 / 17.5 / 17.5 · 0.07 / 0.14 / 0.7 |
| 50 mL | 50 / 25 / 5 | 100 / 100 / 100 · 0.2 / 0.4 / 2.0 | 25 / 25 / 25 · 0.05 / 0.10 / 0.5 |
Accessories:
| Part No. | Accessory | Function |
|---|---|---|
| 17001682 | Reagent Bottle Base Holder | Increase the friction between the bottle base and the workbench to prevent the titrator from sliding or tipping over. |
| 17001681 | Refill Support Base | Secure the long inlet tube while connecting the titrator to the funnel base. |
| 17001680 | Liquid Refill Funnel | Allow easy refilling of the reagent bottle without disassembling the titrator. |
| 17001679 | Liquid Refill Base | The titrator can be placed separately on the workbench. |
| 17900433 | Refill Funnel | Refill solution into the reagent bottle. |
| 17900519 | pH Meter | Assist in titration end-point determination. |
| 17900518 | Bluetooth Printer (thermal) | Print titration results (Bluetooth version available). |
| 17900541 | Color Sensor | Assist in titration end-point determination. |
| 18900909 | Universal Electrode Stand | For placing electrodes or a spiral discharge tube. |
Features
- Electronically driven titration — more accurate, stable, efficient and free from human influence than ordinary digital titrators.
- Three sizes (10 mL, 25 mL, 50 mL) — operation from 10 μL to 50.00 mL with up to two decimal places resolution.
- User-friendly intelligent control panel — clear and easy to operate.
- Touch screen display — perform titration directly, or use the dedicated operating handle for remote titration.
- Clear and brown windows as standard — the brown window can be used for photosensitive media (e.g. iodine, potassium permanganate and silver nitrate solutions).
- Drying tubes supplied as standard — for moisture and CO2 sensitive media.
- Built-in valve with 0–90 degree rotation — rapid exhaust and return reagent, with safety and security features.
- Free software — available for upstream control.
- Three liquid discharge modes — single drop, fixed volume liquid discharge and manual liquid discharge.
- Two suction modes — manual suction and fixed volume suction.
Note: The Ecostir magnetic stirrer shown in the images or application demonstrations is not included in the supply scope of this product and must be purchased separately.
Application
dTrite-Pro is applied to all experiments of the following titration types:
- Acid-base neutralisation titration
- Redox titration
- Precipitation titration
- Complexation titration
It is widely used in the food industry, the pharmaceutical and chemical industry, food and drug safety testing, petrochemicals, environmental testing, metals and plating, surfactants, and third-party testing laboratories. The titration data can be traced.
FAQ
What is dTrite-Pro?
dTrite-Pro is an electronic titrator. Electronic titration is a new product in the field of titration, which is easier, more comfortable, faster and more accurate than a traditional buret.
How does dTrite-Pro compare to an ordinary digital titrator?
The whole process of titration is electronically driven and controlled, so it is more accurate, stable, efficient and free from human influence than ordinary digital titrators.
What titration sizes are available?
dTrite-Pro is available in 10 mL, 25 mL and 50 mL sizes, enabling operation from 10 μL to 50.00 mL with up to two decimal places resolution.
What titration types is dTrite-Pro suitable for?
dTrite-Pro is applied to all experiments of acid-base neutralisation titration, redox titration, precipitation titration and complexation titration.
Which industries use dTrite-Pro?
It is widely used in the food industry, the pharmaceutical and chemical industry, food and drug safety testing, petrochemicals, environmental testing, metals and plating, surfactants, and third-party testing laboratories.
What quality standard does dTrite-Pro comply with?
dTrite-Pro complies with the ISO 8655 quality standard.
What is the operating temperature range?
The operating temperature range is 10–30 °C.
Does dTrite-Pro support Bluetooth and WiFi?
Yes, dTrite-Pro supports both Bluetooth and WiFi functions.
What is the battery capacity and memory?
The battery capacity is 3500 mAh, and the memory stores up to 1000 experimental records.
What screen does dTrite-Pro use?
dTrite-Pro features a 4.3-inch TFT color display with 800×480 resolution.
What is the brown window used for?
The brown window is used for photosensitive media, such as iodine, potassium permanganate and silver nitrate solutions.
Are drying tubes included?
Yes, drying tubes are supplied as standard. For moisture and CO2 sensitive media, it is necessary to use drying tubes with a suitable absorbent (not included in the scope of delivery).
What are the liquid discharge and suction modes?
dTrite-Pro provides three liquid discharge modes (single drop, fixed volume liquid discharge and manual liquid discharge) and two suction modes (manual suction and fixed volume suction).
Can dTrite-Pro be operated remotely?
Yes. The touch screen display makes it easy to perform titration experiments, or remote titration can be performed using the dedicated operating handle.
Is the magnetic stirrer included?
No. The Ecostir magnetic stirrer shown in the images or application demonstrations is not included in the supply scope of this product and must be purchased separately.
What accessories are available for dTrite-Pro?
Available accessories include the Reagent Bottle Base Holder, Refill Support Base, Liquid Refill Funnel, Liquid Refill Base, Refill Funnel, pH Meter, Bluetooth Printer (thermal), Color Sensor and Universal Electrode Stand.
What is the working accuracy of dTrite-Pro?
The working accuracy is defined by the systematic error (R) and the coefficient of variation (CV). For example, the 10 mL model at a nominal volume of 10 mL has a systematic error of ±20 μL (±0.2%) and a coefficient of variation of ±7 μL (±0.07%). Full accuracy data for the 10 mL, 25 mL and 50 mL models is provided in the Specification section.
