Key Features
- Independent heating and stirring control
- LCD display shows actual temperatures and speed
- PID controller ensures a precise and steady heating process, Max. temperature up to 340℃
- Brushless DC motor enables more powerful speed control
- External temperature sensor(PT1000) with accuracy at 0.2℃
- Overheating protection temperature at 420℃
- Stainless steel work plate with ceramic coating provides good chemical-resistant performance
- A wide variety of accessories are available
Specifications
| Specifications | MS-H340-S4 |
| Work plate dimension | Φ135mm(5inch) |
| Plate material | Stainless steel with ceramic coating |
| Motor type | Brushless DC motor |
| Motor rating input | 1.8W*4 |
| Power | 515W*4 |
| Heating Power | 500W*4 |
| Voltage | 100~120V,60Hz; 200~240V,50 Hz |
| Stirring positions | 4 |
|
Max. stirring quantity of single position (H2O) |
10L |
| Max. magnetic bar | 40mm |
| Speed range | 200~1500rpm |
| Display | LCD (Speed, Temperature) |
| Control accuracy of sensor[rpm] | ±20 |
| Temperature range | 25-340℃ |
| Over temperature protection | 420°C |
| Temperature display accuracy | ±0.1°C |
| External temp. sensor | PT1000 (Accuracy±0.2℃) |
| IP Protection class | IP21 |
| Dimensions[W*D*H] | 698*270*128mm |
| Weight | 9.5kg |
| Permissible ambient temperature | 5～40°C |
| Permissible relative humidity | 80%RH |
