$689.00
Sku: MS7-H550-Pro-Package2
Specification
Include: MS7-H550-Pro (8030122111) + PT1000A(18900016)+ support clamp(18900017)
PT1000A(18900016)
Support Clamp 18900017
Key Features
- High-Temperature Resistance: Glass ceramic work plate ensures excellent chemical resistance and efficient heat transfer, with a maximum temperature setting of 550°C.
- Precise Temperature Control: Built-in PID controller with external temperature sensor (PT1000) delivers accuracy within ±0.2°C for safe and stable heating, supported by reliable performance data.
- Powerful Stirring Capacity: Capable of stirring up to 20 liters of liquid, powered by a durable brushless DC motor for enhanced stirring performance.
- Digital Control and Monitoring: LCD display allows precise monitoring and easy adjustment of speed (up to 1500 RPM) and temperature.
- Safety Features: “HOT” warning indicator flashes when the work plate temperature exceeds 50°C, even after the unit is turned off.
- Durable Design: Aluminum alloy housing provides excellent chemical resistance and durability in demanding lab environments.
- Remote Operation: RS232 connectivity enables PC control and data transmission for seamless integration with lab systems.
Specifications
| Specification | MS7-H550-Pro |
| Work plate Dimension [W * D] | 184 * 184mm (7 inch) |
| Work plate material | Glass ceramic |
| Motor type | Brushless DC motor |
| Motor rating input/output | 18W/10W |
| Power | 1050W |
| Heating output | 1000W |
| Voltage | 100-120/200-240V 50/60Hz |
| Stirring positions | 1 |
| Max. stirring quantity, [H2O] | 20L |
| Max. magnetic bar[length] | 80mm |
| Speed range | 100~1500rpm resolution ±1rpm |
| Speed display &Temperature display | LCD |
| Heating temperature range | Room Temp.-550°C, increment 1°C |
| Temperature control accuracy | ±1 °C (<100°C) ±1%(>100°C) |
| Overheating protection | 580°C |
| Temperature display accuracy | ±0.1°C |
| External temperature sensor | PT1000 (Accuracy ±0.2) |
| "Hot" warning | 50°C |
| Data connector | RS232 |
| Protection class | IP21 |
| Dimension [W*D*H] | 215*360*112mm |
| Weight | 5.3kg |
| Permissible ambient temperature and humidity | 5-40°C, 80%RH |
