Specifications

Parameter	Specification
Cat.No.	8032220100
Motion Type	Orbital Shaker
Amplitude	10 mm
Tilt Angle	-
Speed Range	100–500 rpm
Speed Display	LCD
Timer Display	LCD
Time Settings Range	1 min – 99 h 59 min
Data Connector	RS232
Max. Load Capacity (with Platform)	7.5 kg
Motor Type	Brushless DC motor
Motor Rating Input	28 W
Motor Rating Output	15 W
Power	30 W
Voltage	100–240 V
Frequency	50 / 60 Hz
Dimension [W × D × H]	370 × 420 × 100 mm
Work Plate Dimension [W × D]	320 × 320 mm
Weight	12 kg
Permissible Ambient Temperature	5–40 ℃
Permissible Ambient Humidity	80% RH
Protection Class	IP21
