Specification

Cat. No.	Volume Range	Graduation	Systematic Error		Random Error
Cat. No.	mL	mL	μL	%	μL	%
7032100101	0.5-5	0.1	±25	±0.5	±10	±0.2
7032100102	1.0-10	0.2	±50	±0.5	±20	±0.2
7032100103	2.5-25	0.5	±125	±0.5	±50	±0.2
7032100104	5.0-50	1.0	±250	±0.5	±100	±0.2

Cat. No.	17400131	17400132	17400133	17400134	17400135	17400037	17400021	17400073	17400553	17400696	17100767
Accessories	GL32, Adapter, 45/32mm	GL38, Adapter, 45/38mm	GL25, Adapter, 45/25mm	GL28, Adapter, 32/28mm	S40, Adapter, 45/40mm	Reagent Bottle (Brown, 1L)	Filling tube （m）	Discharge tube(m)	GL45, adapter, 45mm	Discharge tube combination （adapter 25mL、50mL）	Discharge tube combination （adapter 5mL、 10mL）

Key Features

Excellent chemical resistance, Inert and high strength components made of PTFE, FEP, BSG, PP
Fully autoclavable at 121℃ (only liquid accessible parts)
Available in 4 dispensing volume ranges from 0.5mL to 50mL
Easy to disassemble and clean for periodic maintenance
Supplied with most popular adapters (S40, GL32, GL38, GL25, GL28)

Applications

bottle-top dispensers oﬀer high precision and accuracy with ISO 8655

conformed calibration for use in areas such as pharmacology, biotechnology, healthcare, food and beverage, chemistry, environmental monitoring and academy&research

Easy-to-use volume adjustment
Smooth piston design provides eﬀortless dispensing experience
Easy-to-use closure cap protects user from exposure to reagent
Adapters to comfortably ﬁt most laboratory reagent bottles

Parts List

Part Name	Quantity
Dispenser Main Body	1
Inlet Tube (Intake Tube)	1
Discharge Tube (Outlet Nozzle)	1
Plunger Knob / Handle Extension	1
Bottle Neck Adapters (Threaded)	GL25 Adapter (32/25 mm)	1
	GL28 Adapter (32/28 mm)	1
	GL32 Adapter (45/32 mm)	1
	GL38 Adapter (45/38 mm)	1
	S40 Adapter (45/40 mm)	1

Compatibility

This dispenser is ready to use with just a bottle — no additional accessories are needed. We provide five standard bottle adapters (GL25, GL28, GL32, GL38, and S40), making it compatible with most common laboratory reagent bottles.

If you’re unsure about compatibility, you can also choose from our selection of high-quality reagent bottles designed to fit perfectly with this dispenser.

Documents

DispensMate

Bottle-Top Dispenser Chemical Compatibility sheet-EN-2024.7.2

DispensMate Bottle - Top Dispenser
