Description

"Manage thousands of frozen samples with labels that peel off in liquid nitrogen, racks that lose position tracking, and tubes that become unreadable once frost builds up. Then try to automate the workflow afterward. Skip all of that."

Every Biofargo CryoMark® 2.0 mL Cryotube is designed for automated cryogenic storage, secure sample traceability, and SBS-compatible laboratory workflows: a sterile polypropylene cryogenic vial featuring a triple-code identification system, φ12.8 mm self-standing tube structure, and high-contrast white code on a black background for dependable barcode readability under frozen storage conditions. Each tube includes side barcode, bottom 2D DataMatrix, and human-readable code to support redundant sample verification and digital inventory integrity.

The external thread structure minimizes contamination risk within the sealing area while supporting dependable leak resistance during ultra-low temperature storage and transport. The SBS 6 × 8 box-packed configuration is optimized for automation-compatible storage systems and robotic workflows, while the cryobox includes both side and bottom identification codes for fast rack-level tracking and freezer inventory management. Designed for liquid nitrogen resistant performance, the system supports reliable long-term cryogenic preservation in demanding biobanking environments.

Compatible with VisionMate, Ziath, and Thermo Scientific 2D barcode readers. Works in Matrix, FluidX, and Micronic SBS automation platforms.

Features

● Ready-to-Store out of the case — 48 tubes pre-racked in a 6 × 8 ANSI/SLAS SBS cryobox. No rehousing for −80 °C mechanical freezers or LN2 vapor-phase tanks.
● Clear Tube + Laser-Etched Black Barcode Strip — See every sample at a glance while keeping the side code high-contrast and peel-proof.
● Triple-Code Barcode Redundancy — Side, bottom, and human-readable. Meets 21 CFR Part 11 and biobank data-integrity requirements.
● −196 °C Leak-Proof, Validated — External screw cap, non-silicone sealing. Passes negative-pressure and freeze–thaw testing. Meets IATA PI650 transport.
● RNase/DNase-Free, Endotoxin ≤ 0.005 EU/mL — Sterile, gamma-irradiated. Drop-in for molecular diagnostics and clinical biobanking.
● Reader-Agnostic — Works natively with industry-standard 2D decoders. No proprietary lock-in.
● SBS Automation Compatible — ANSI/SLAS footprint supports robotic handlers, automated freezers, and high-throughput sample management systems.
● Bulk-Ready with Batch Traceability — 48 tubes/box, 50 boxes/case. Precision-molded with full lot traceability.

Specifications

Parameter	Specification
Product Name	CryoMark® 2.0 mL Triple-Code Cryotubes, SBS 6 × 8 Format, External Thread
SKU	413169
Material	Polypropylene (PP), RNase/DNase-Free, Endotoxin ≤ 0.005 EU/mL
Working Volume	2.0 mL
Tube Design	External thread, φ12.8 mm self-standing tube
Barcode System	Triple-code: white code on black background + bottom 2D DataMatrix + human-readable code
Format	SBS 6 × 8 box-packed format
Cryobox Identification	Box with side and bottom identification codes
Cryogenic Resistance	Liquid nitrogen resistant
Sterility	Sterile, gamma-irradiated
Package	48 pcs/box · 50 boxes/case (2,400 tubes)

Applications

Automated Biobanking — Barcode-based sample storage, freezer inventory management, and robotic retrieval workflows.
Long-Term Cryogenic Storage — DNA, RNA, plasmids, proteins, cells, and microbial sample preservation.
Clinical & Biopharma Laboratories — Secure traceability and organized sample handling for regulated workflows.
LIMS & Automation Integration — Compatible with automated sample handlers, barcode readers, and digital inventory systems.
Liquid Nitrogen Storage Workflows — Reliable cryogenic preservation and transport in LN₂ storage environments.

Pre-filled 2.0 mL CryoMark® Cryo Tubes, Triple-Code, Liquid Nitrogen Resistant, Black Self-standing Tube, 6×8 Cryobox, 48/Box, Sterile
